White Coffing electric chain hoist labeled "1/2 TON" is suspended from a black overhead beam, with a chain, hook, and red handheld control attached.
ED
EDT-4008

COFFING ED HOIST 2 TON, 8 FPM, SUSPENSION: PUSH TROLLEY

COFFING
  • Item Number: EDT-4008
Request Info

Attributes

Attribute Value
Lift 10 FT.
Capacity 2 TON
Hoist Control 1-SPEED
Hoist Lifting Speed 8 FPM
Reeving 2 PART
Suspension PUSH TROLLEY

Product Description

Coffing ED Models offer extended duty service for special applications which require a hoist that exceeds the duty rating of basic EC models

Features and Benefits

  • Capacities and Lifts
    Rated loads from 1/4 to 2 Tons, with 10, 15, and 20-foot standard lifts. Other lifts available. Standard push button drop is 4-feet less than lift.
  • Suspension Options
    Rigid lug; plain, geared, and motorized trolleys.
  • Load Chain
    Zinc plated standard for corrosion resistance.
  • Accessories
    Full line of options to meet a variety of applications.
  • Voltage and Motor Options
    230/460, three-phase motors standard. Totally enclosed, fan-cooled motor keeps both motor and transmission from overheating. Consult factory for other voltage and speed options.
  • Duty Cycle
    Exceeds H4 duty service.
  • External Strain Relief
    Secures to NEMA 3R push button station with extra strain relief protection.
  • Lifetime Warranty
